Description
-
FrameFORM™ Alloy | Integrated Display | Mid-High Pivot Smoothlink Suspension System | Press Fit BB | 2-Bolt ISCG05 Tabs | RIDE-9™ Adjustable Geometry + Suspension Rate | 140mm Travel. FORM™ Alloy Rear Triangle
-
ForkRockShox Lyrik Select RC 150mm | 42mm Offset
-
Front Travel150
-
ShockRockShox Deluxe Select+ | Sealed Bearing Eyelet | 25x8mm F Hardware | All Sizes = 210x55mm | Size-Specific tune in FAQ
-
Rear Travel140
-
HeadsetFSA Orbit NO.57E | Sealed 36°x45° Bearings | 30.2mm x 41mm x 7.1mm Upper | 40mm x 51.8mm x 7.5mm Lower | 1.5" Crown Race
-
StemRocky Mountain 35 AM | 5° Rise | All Sizes = 40m
-
HandlebarRocky Mountain AM | 780mm Width | 25mm Rise | 9° Backsweep | 5° Upsweep | 35 Clamp
-
GripsODI Elite Pro Lock On
-
BrakesShimano XT Trail 4 Piston | Metal Pads | F:Shimano RT66 203mm | R:Shimano RT66 203mm
-
ShiftersShimano XT
-
Rear DerailleurShimano XT
-
Cranks & ChainringRace Face Aeffect Cinch 34T | 24mm Spindle | Crank Length: SM - MD = 165mm | LG - XL = 170mm
-
Bottom BracketShimano SM-BBMT500
-
CassetteShimano SLX 10-51T
-
ChainShimano M7100
-
Front HubRocky Mountain Sealed Boost 15mm
-
Rear HubDT Swiss Hybrid 370 Boost 148mm | 18T Star-Ratchet
-
SpokesF : DT Swiss Champion 2.0 | R : DT Swiss Alpine 2.3/2.0
-
RimsWTB ST i30 TCS 2.0 Tubeless | 32H | Tubeless Ready - Tape / Valves Incl
-
TiresF: Maxxis Minion DHF 2.5 WT 3C MaxxTerra EXO+ Tubeless Ready // R: Maxxis Minion DHR II 2.4 WT 3C MaxxTerra EXO+ Tubeless Ready
-
SeatpostRace Face Aeffect R Dropper 30.9mm | Shimano MT500 Remote | SM = 125mm | MD = 150mm | LG - XL = 170mm
-
SaddleWTB Volt Race 142
-
Drive SystemDyname 4.0 Mountain Bike Drive | 250w Nominal Power | 108Nm | Rocky Mountain Micro Remote | Low RPM - High Efficiency class 1 eMTB System | Designed in Canada
-
Battery720 Wh Removable Integrated Li-Ion | 100% Charged in 3:55 (4A) / 7:35 (2A) | 80% Charged in 2:55 (4A) / 6:05 (2A)
-
RemoteRocky Mountain Micro Remote
-
DisplayRocky Mountain Jumbotron | Drive System Customization | Battery & Assist Level | Trip | Speed | Cadence | Top Tube Integration
-
ChargerRocky Mountain Powerplay FAST Charger | 4A | 48V | Higo Deep Socket Connector | Overtimepack Compatible (Dyname 4)
-
Weight52.9 LBS|24 KGS
-
NotesWe make every effort to ensure accuracy, but reserve the right to update specifications & prices without notification.
Item Specific Details
UPC: 770416442649
